Portable Water Monitor 1000-2000 , LPM,7kg.cm2
Capacity (Flow rate)
1000 TO 2000 LPM @ 7 kg/cm2
Double Inlet. 2 X 63 MM Male INST. With NRV . (Non return valve)
Enclosed hand wheel driven worm gear.
30.0 degree to 90.0 degree
Above 180 degree . manual rotation
Foldable ground base with hardened steel spikes
1000-2000 LPM@ 7kg cm2. Controlled with flow , Controlled Ring. Manually,
To automatically adjust change in Pressure and maintain throw.
Horizontal Throw @30??
45 MTR @ 7 kg.cm2
25 MTR. @ 7kg.cm2 .
Material of construction
Swivel joints assy. upper elbow assembly , Nozzle, Barrel pipe hard anodized Alloy Aluminum parts hard anodized
Fire red powder coating all part inside and out side and water way for corrosion protection.
