Trolly Mounted Foam Water monitor

Trolly Mounted Foam Water monitor
Trolly Mounted Foam Water monitor
Send Inquiry
Product Code : BEW/900
Brand Name : BRILLIANT
Product Description
MonitorPortable Water Monitor 1000-2000 , LPM,7kg.cm2
Capacity (Flow rate)1000 TO 2000 LPM @ 7 kg/cm2
Inlet connectionDouble Inlet. 2 X 63 MM Male INST. With NRV . (Non return valve)
Vertical Rotation

Enclosed hand wheel driven worm gear.

30.0 degree to 90.0 degree

above

Horizontal RotationAbove 180 degree . manual rotation
StandFoldable ground base with hardened steel spikes
Nozzle Flow

1000-2000 LPM@ 7kg cm2. Controlled with flow , Controlled Ring. Manually,

To automatically adjust change in Pressure and maintain throw.

Horizontal Throw @30??45 MTR @ 7 kg.cm2
Vertical Throw25 MTR. @ 7kg.cm2 .
Spray Angle120 degree
Special FeatureAble to dismantle in two parts for easy Carrying
Material of constructionSwivel joints assy. upper elbow assembly , Nozzle, Barrel pipe hard anodized Alloy Aluminum parts hard anodized
Finish

Powder coating

Fire red powder coating all part inside and out side and water way for corrosion protection.

  • Minimum Order Quantity: 100 Piece
